PVC Transparent Rigid Sheet

Basic Info

  • Model NO.: KS-PVC Clear
  • Material: PVC
  • Kind: Transparent Plastic Sheet
  • Water Absorption: 0.1%~0.3%
  • Contraction Percentage: <0.4%
  • Tensile Strength: 700
  • Size: 1220*2440mm, or Any Length as Required
  • Trademark: Kingstar
  • Transport Package: in Rolls and Pallets
  • Specification: GB/ASTM
  • Origin: China
  • HS Code: 3920109090
  • Product Description

Products Details

Description PVC Transparent Rigid Board/Sheet/Panel; PVC Clear Rigid Board/Sheet/Panel;
Width(mm) 0~1500mm
Length(mm) Any Length.  1830, 2000, 2440, 3000 etc.
Thickness(mm) 0.04~0.2mm: Max. width, 1500mm;     0.2-20mm: Max. width, 1300mm
Density  1.4g/cm3;
Surface Glossy, matt
Colors Bluish Clear, water clear or other color: grey, brown, red in transparent available

Features

  1. Suitable for thermoforming, bending & fabricating

  2. Excellent in chemical resistance, ideal material for chemical & corrosive condition

  3. High fireproof rating, self-extinguishing

  4. Strong and rigid

  5. Safe, innocuous for man's body

  6. Excellent electrical and thermal insulation ability

  7. ) High impact strength

  8. Anti-UV; Weather resistant

  9. Low moisture absorbability

Application

  1. Decoration: face plate of photograph frame, jewelry case

  2. Advertising field: screen printing and UV printing, show shelf

  3. Indoor applications: wall panel, partition sheets, windshield plate

  4. Polluted areas

  5. Electrical room


Mechanical Features

PROPERTY TEST METHOD (ASTM D) CONDITION VALUE(Based on 15mm) UNIT
Tensile Strength at Yield ASTM D 638 Specimen: Type I
Speed: 10mm/min
10MPa 1,450psi
Elongation at Break Specimen: Type I
Speed: 10mm/min
5 %
Tensile Modulus Specimen: Type V
Speed: 1mm/min
700 Mpa
Flexural Strength ASTM D 790 127×12.91×3.77mm
Speed: 1.6mm/min
Span: 59mm
12.6MPa 18,270psi
Flexural Modulus 460MPa 66,700psi
Impact Strenght ASTM D6110-06 With:6.65mm;
Depth:12.86mm
Heating rate:120℃/h
Load:0.455Mpa
15 J/m
Dielectric Strength ASTM D 149 10 kv/mm

Physical Features

PROPERTY TEST METHOD (ASTM D) CONDITION VALUE(Based on 15mm) UNIT
Specific Gravity ASTM D 792 0.6 g/cm3
Water Absorption ASTM D 570 76.2mm×25.4mm
Drying: 50℃,24hrs;
Immersion: 25℃,24hrs
0.37 %
Shore D Hardness ASTM D 2240 Type D 63 D

Thermal Features

PROPERTY TEST METHOD (ASTM D) CONDITION VALUE(Based on 6mm) UNIT
Heat Deflection Temperature ASTM D648-07 Method B Width:6.65mm;
Depth:13.07mm
Heating rate:120℃/h;
Load:1.82MPa
61.4
Width:6.65mm; Depth:12.86mm
Heating rate:120℃/h; Load:0.455MPa
70.9
Heat Distortion Temperature (under load at 264 psi) ASTM D 648 120
Coefficient of linear Expansion ASTM D 696 2.9×10ˉ5 in/in/°F
Thermal Conductivity ASTM D 177 0.06 W/m°K



Packing

PE bags package for 1220*2440mm

Wood pallets package for 900*1500mm

Steel pallets package for 1500*3000mm
